| Rated load capacity | 3000KG | ||
| Load center distance | 600 | ||
| Minimum fork height | 80mm | ||
| Front wheel | φ160X55 | ||
| Rear wheel | φ80/70 | ||
| Maximum lifting height | 200 | ||
| Maximum/minimum height at drive position | 770/1254 | ||
| Overall length | 1750mm | ||
| Fork length | 1160 | ||
| Fork size | 160/1160 | ||
| Overall fork width | 550/685 | ||
| Full charge range | 480 min | ||
| Charging time | 520 min | ||
| Turning radius | 1515mm | ||
| Operating speed, loaded/unloaded | 4/5.5 | ||
| Lead-acid battery | 48V/20A | ||
| Battery weight | 25KG | ||
| Weight (with battery) | 145KG | ||
| Motor power | 800W | ||
A lead-acid battery pallet truck is a traditional motorised material handling tool. It uses standard lead-acid batteries to power its propulsion and lifting systems. While facing competition from newer lithium-ion technology, these heavy-duty units remain a standard, cost-effective staple in high-volume warehouses and industrial yards worldwide.
Key Characteristics & Trade-offs
- Lower Upfront Cost: Requires a significantly smaller initial financial investment compared to lithium-ion models.
- Heavy Counterweight: The physical weight of lead-acid blocks naturally improves truck stability when lifting max capacities.
- Strict Charging Rules: Requires a strict 8-hour charge followed by an 8-hour cool-down period to prevent battery damage.
- Regular Maintenance: Demands weekly fluid top-offs with distilled water and routine cleaning to prevent acid corrosion.
- Dedicated Charging Areas: Must be charged in specialized, well-ventilated rooms due to the release of explosive hydrogen gas.
Customisation Options: As a leading Construction Machinery & Warehouse Equipment Supplier, we offer OEM services
