Product Description

Master the most demanding compaction tasks with our Professional 90kg Vibratory Plate Compactor. Engineered for elite industrial performance, this heavy-duty machine delivers a massive 18kN centrifugal force, ensuring deep-reaching vibration to effectively eliminate air pockets in sub-base materials. Driven by a high-torque 6.5HP industrial engine, it provides the raw power and stability required for national highway repairs, commercial foundations, and large-scale landscaping.

The unit features a specialized integrated large-capacity water tank, essential for asphalt paving to prevent hot-mix adhesion and provide professional dust control. With its oversized 500*520mm ductile iron base plate, the machine offers exceptional coverage and stability at speeds up to 20 m/min. Designed with operator efficiency in mind, it includes a vibration-dampened handle and a heavy-duty transport wheel kit, making it the definitive choice for professional contractors seeking industrial-grade durability and surgical precision on every job site.

---

Key Features

• Elite 18kN Centrifugal Force: Delivers intense vibratory energy reaching deep into the sub-grade for high-density compaction in fewer passes.

• Integrated Asphalt Sprinkling System: Features a large-capacity water tank and spray bar, perfect for hot-mix asphalt work and site dust suppression.

• High-Output 6.5HP Engine: Reliable power delivery with an easy-start recoil system, designed for 24/7 heavy-duty onsite operation.

• Heavy-Duty Ductile Iron Base: The wear-resistant, self-cleaning base plate with curved edges ensures smooth maneuvering and a ridge-free finish.

• Superior Vibration Isolation: Outfitted with professional-grade shock mounts to minimize hand-arm vibration, significantly protecting the operator during long shifts.

• Built-in Heavy-Duty Wheels: Equipped with a fold-down transport wheel system, allowing a single person to move the 90kg machine across the job site effortlessly.

• Reinforced Protective Frame: A rugged steel engine cage protects the motor from impacts and provides a secure central lifting point for cranes.

Applications

• Professional Road Construction: Ideal for asphalt patching, highway shoulder repair, and street maintenance.

• Deep Foundation Stabilization: The primary choice for compacting thick layers of gravel, sand, and mixed soils before pouring concrete slabs.

• Infrastructure & Utility Work: Highly effective for compacting backfill in wide utility trenches and around large structural foundations.

• Commercial Landscaping: Perfect for leveling and stabilizing ground for large plazas, sports tracks, and synthetic turf sub-bases.

• Paving & Hardscaping: Essential for settling interlocking bricks and large pavers into bedding sand for high-traffic walkways.

---

Technical Parameters

---
